Description
PERFORMANCE | |
Processor |
Intel® Core™ i5-1130G7 (4C / 8T, 1.8 / 4.0GHz, 8MB)
|
Graphics |
Integrated Intel® Iris® Xe Graphics
|
Chipset |
Intel® SoC Platform
|
Memory |
16GB Soldered LPDDR4x-4266, POP Memory
|
Memory Slots |
Memory soldered to systemboard, no slots, dual-channel
|
Max Memory |
16GB soldered memory, not upgradable
|
Storage |
256GB SSD M.2 2242 PCIe® 3.0x4 NVMe®
|
Storage Support |
One drive, up to 1TB M.2 2242 SSD
|
Card Reader |
None
|
Optical |
None
|
Audio Chip |
High Definition (HD) Audio, Realtek® ALC3286 codec
|
Speakers |
Stereo speakers, 2W x2, Dolby® Atmos®
|
Camera |
HD 720p + IR Hybrid with Privacy Shutter
|
Microphone |
4x, Array
|
Battery |
Integrated 44.5Wh
|
Max Battery Life |
MobileMark® 2018: 11.7 hr JEITA 2.0: 16.8 hr
|
Power Adapter |
65W USB-C® Slim (3-pin)
|
DESIGN | |
Display |
13.5" QHD (2256x1504) IPS 450nits Anti-reflection / Anti-smudge. 72% NTSC, Dolby® Vision™, Touch
|
Touchscreen |
OGM, 10-point Multi-touch
|
Keyboard |
Backlit, English (UK)
|
Case Color |
Titanium
|
Case Material |
Titanium + Carbon Fiber (Top), Magnesium-aluminium (Bottom)
|
Pen |
Pen Upgradable (Purchase Separately)
|
Dimensions (WxDxH) |
297.5 x 232.7 x 11.5 mm (11.71 x 9.16 x 0.45 inches)
|
Weight |
Starting at 1.15 kg (2.54 lbs)
|
SOFTWARE | |
Operating System |
Windows® 10 Pro 64, English
|
Bundled Software |
None
|
CONNECTIVITY | |
Ethernet |
No Onboard Ethernet
|
WLAN + Bluetooth |
Intel® Wi-Fi® 6 AX201, 11ax 2x2 + BT5.1
|
WWAN |
None
|
SIM Card |
None
|
NFC |
None
|
Standard Ports |
|
Optional Ports (configured) |
None
|
Docking |
Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® X1 Titanium Yoga® Gen 1
|
Monitor Cable |
None
|
SECURITY & PRIVACY | |
Smart Card Reader |
None
|
Security Chip |
Discrete TPM 2.0
|
Fingerprint Reader |
Touch Style, Match-on-Chip, on the Top Right of Keyboard
|
Physical Locks |
Kensington® Nano Security Slot™
|
Other Security |
|
MANAGEABILITY | |
System Management |
Non-vPro®
|
SERVICE | |
Base Warranty |
3-year, Courier or Carry-in
|
Included Upgrade |
3Y Premier TP Halo WHB (CPN) (5WS1B09495)
|
ACCESSORIES | |
Bundled Accessories |
None
|
CERTIFICATIONS | |
Green Certifications |
|
Other Certifications |
Intel® Evo™ Platform
|
Mil-Spec Test |
MIL-STD-810H military test passed
|
